掌旗手单位 | 固定旗帜

很久之前制作的旗手单位,主要模型是旗杆,然后旗杆附加一个国旗挂件,分三个版本
flag.rar





以下全部是旗杆的语句,人物你自己随变找个单位就行,动作用掌旗手的


随国家改变国旗(包括革命旗帜)
<?xml version="1.0" encoding="utf-8"?>

<animfile>
	<definebone>bone_flag_bottom</definebone>
	<attachment>
		flag
		<component>
			flag
			<assetreference type="ClothFlag">
				<flag>
					<blending>alphatest_color</blending>
					<specialtexture/>
					<width>2.00</width>
					<height>1.25</height>
				</flag>
			</assetreference>
		</component>
		<anim>
			Idle
			<component>flag</component>
		</anim>
	</attachment>
	<component>
		pikes
		<logic type="Tech">
			<none>
				<assetreference type="GrannyModel">
					<file>mods\flag\flagpole</file>
				</assetreference>
				<attach a="flag" frombone="flag" tobone="bone_flag_bottom" syncanims="0"/>
			</none>
		</logic>
	</component>
	<anim>
		Idle
		<component>pikes</component>
	</anim>
</animfile>


玩家色国旗 <?xml version="1.0" encoding="utf-8"?> <animfile> <definebone>bone_flag_bottom</definebone> <attachment> flag <component> flag <assetreference type="ClothFlag"> <flag> <blending>alphatest_color</blending> <texture>MODS\flag\flagplayer</texture> <width>2.00</width> <height>1.25</height> </flag> </assetreference> </component> <anim> Idle <component>flag</component> </anim> </attachment> <component> pikes <logic type="Tech"> <none> <assetreference type="GrannyModel"> <file>mods\flag\flagpole</file> </assetreference> <attach a="flag" frombone="flag" tobone="bone_flag_bottom" syncanims="0"/> </none> </logic> </component> <anim> Idle <component>pikes</component> </anim> </animfile>
固定国旗 <?xml version="1.0" encoding="utf-8"?> <animfile> <definebone>bone_flag_bottom</definebone> <attachment> flag <component> flag <assetreference type="ClothFlag"> <flag> <blending>pixelxform</blending> <texture>MODS\flag\Eighteenstarflag</texture> <width>2.00</width> <height>1.25</height> </flag> </assetreference> </component> <anim> Idle <component>flag</component> </anim> </attachment> <component> pikes <logic type="Tech"> <none> <assetreference type="GrannyModel"> <file>mods\flag\flagpole</file> </assetreference> <attach a="flag" frombone="flag" tobone="bone_flag_bottom" syncanims="0"/> </none> </logic> </component> <anim> Idle <component>pikes</component> </anim> </animfile> 随玩家国旗很容易就能从其他文件找到 <assetreference type="ClothFlag"> <flag> <blending>alphatest_color</blending> <specialtexture/> <width>2.00</width> <height>1.25</height> </flag> </assetreference> 玩家色国旗就是在上面的基础添加了一张贴图 <assetreference type="ClothFlag"> <flag> <blending>alphatest_color</blending> <texture>MODS\flag\flagplayer</texture> <width>2.00</width> <height>1.25</height> </flag> </assetreference> 然后当你尝试将贴图改成固定国旗后,无论怎样那张国旗都会附加玩家色,原因在于 <blending>alphatest_color</blending> 找遍了所有bar文件(art.bar、art4.bar、art5.bar) 会发现只有一个garrison_flag.xml存在没有玩家色的设定,将blending修改成<blending>pixelxform</blending> <!-- converted from XMB to XML --> <animfile> <component> ModelComp <assetreference type="ClothFlag"> <flag> <blending>pixelxform</blending> <texture>ui\garrison_flag\garrison_flag</texture> <width>2.00</width> <height>1.20</height> </flag> </assetreference> </component> <anim> Idle <component>ModelComp</component> </anim> </animfile> 对于找不同,<specialtexture>与<texture>作用是一样的 以下内容未经测试,有兴趣可用自己尝试 2022-9-12翻exe内存字符串,找到一个可用alphatest_nocolor,可能是不带通道颜色,正常贴图? 使用方法 <assetreference type="ClothFlag"> <flag> <blending>alphatest_nocolor</blending> <specialtexture/> <width>2.00</width> <height>1.25</height> </flag> </assetreference> 以下内容看看就好,99%无功而返。 可能还有一个GeometryTrail标签,根据翻译是几何轨迹,盲猜是法线贴图之类的?? 盲猜使用方法(成功概率0.1%) <assetreference type="ClothFlag"> <flag> <blending>alphatest_nocolor</blending> <specialtexture/> <width>2.00</width> <height>1.25</height> <GeometryTrail>贴图文件</GeometryTrail> </flag> </assetreference> 也有可能是用于, <assetreference type="GeometryTrail"></assetreference>使用方法不明
